From £1,650 per tonne, fabricated and primed
Structural steelwork
Beams, columns, bracing and baseplates fabricated to BS EN 1090-2 at EXC2, CE marked, blasted and primed, and erected by our own squad.
- Price from
- £1,650
- Lead time
- 15 working days
- Quote back
- 2 working days
Specification
What the machines take.
- Standard
- BS EN 1090-2, execution class EXC2
- Single length
- Up to 12 m
- Lifting
- 5 t overhead crane, 12 m span
- Sections
- UB, UC, PFC, RHS, SHS, CHS, angle
- Finish
- Blast SA2½, zinc phosphate primer 75 µm
- Paperwork
- DoP, CE mark, mill certs, weld records
How we do it
Structural steel is where paperwork matters as much as welding. We are certified to BS EN 1090-1 at execution class EXC2, which means every beam leaves with a CE mark, a declaration of performance, and material you can trace back to the cast it was rolled from.
Fabrication drawings come back to you and your engineer for signature before anything is cut. Sections are sawn and drilled on the line, baseplates and cleats come off the laser, and everything is welded to procedure and inspected against the approved drawing.
Primed steel goes out on our own wagon and, if you want it, goes up with our own squad: mezzanines, portal frames, plant decks and remedial steel, across the North West and North Wales.
Included as standard
- Connection design checked with your engineer
- Fabrication drawings for your approval
- Material traced to cast number
- Erection by our own CSCS and IPAF squad
“They built the balustrade to the fold detail we actually drew, not the nearest stock section. Samples on the bench a week before anything was cut.”
Questions about structural
Do you do the steel design?
We work from your engineer's design and handle connection detailing. If you have no engineer, we can introduce one we work with.
How is the price per tonne worked out?
It is a guide for plain beams and columns. Connections, holes and finish move it, so the quote is built from the drawing, not the tonnage.
Often ordered together
Other services
Laser cutting
A 6 kW fibre laser on a 3,000 × 1,500 mm bed. Mild steel to 25 mm, stainless to 20 mm, aluminium to 16 mm, cut to ±0.1 mm straight from your DXF.
From £45 per order of simple parts
5 working days
Press-brake bending
A 160-tonne CNC press brake with a six-axis back gauge. Folds up to 3.2 m in one hit, first-off parts measured before the batch runs.
From £1.20 per bend, plus £35 set-up
7–10 working days
Welding and fabrication
MIG, TIG and MMA in five bays, by welders coded to BS EN ISO 9606-1. Frames, brackets, chassis, tanks and one-off repairs at a £58 an hour shop rate.
From £58 per hour shop rate, £145 minimum
10–15 working days
